Description
SUPPORTED SAMPLE RATES
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
MICROPHONE INPUTS
- Frequency Response
- 20Hz – 20kHz ± 0.1dB
- Dynamic Range
- 111dB (A-weighted)
- THD+N
- <0.0012%
- Noise EIN
- -128dBu (A-weighted)
- Maximum Input Level
- 9dBu (at minimum gain)
- Gain Range
- 56dB
- Impedance
- 3kΩ
LINE INPUTS 1-4 (VARIABLE GAIN)
- Frequency Response
- 20Hz – 20kHz ± 0.1dB
- Dynamic Range
- 110.5dB (A-weighted)
- THD+N
- <0.002%
- Maximum Input Level
- 22dBu (at minimum gain)
- Gain Range
- 56dB
- Impedance
- 60kΩ
LINE INPUTS 5-8 (FIXED GAIN)
- Frequency Response
- 20Hz – 20kHz ± 0.1dB
- Dynamic Range
- 110.5dB (A-weighted)
- THD+N
- <0.002%
- Maximum Input Level
- 18dBu (at minimum gain)
- Impedance
- 44kΩ
INSTRUMENT INPUTS
- Frequency Response
- 20Hz – 20kHz ± 0.1dB
- Dynamic Range
- 110dB (A-weighted)
- THD+N
- <0.03%
- Maximum Input Level
- 12.5dBu (at minimum gain)
- Gain Range
- 56dB
- Impedance
- 1.5MΩ
LINE/MONITOR OUTPUTS
- Dynamic Range (Line Outputs)
- 108dB
- THD+N
- <0.002%
- Maximum Output Level (0 dBFS)
- 15.5dBu
- Impedance
- 430Ω
HEADPHONE OUTPUTS
- Dynamic Range
- 104dB (A-weighted)
- THD+N
- <0.002%
- Maximum Output Level
- 7dBu
- Impedance
- <1Ω
